Aluminum

LIAN LI A3-mATX Mini Chassis

Lian-Li

A3-MATX-X

The LIAN LI & DAN Cases A3-mATX is a versatile M-ATX mesh PC case that maintains a minimal chassis size while accommodating large components. Thanks to the relocatable PSU bracket, the A3-mATX empowers you to build a powerful and compact PC system tailored to your needs and preferences.

Found a better price? Let us know and we'll try and match it!
Estimación de envío
2 en stock
$69.99
Los gastos de envío se calculan en la pantalla de pago.

Retiro disponible en Performance-PCs.com

Normalmente está listo en 1 hora

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

The LIAN LI & DAN Cases A3-mATX is a versatile M-ATX mesh PC case that maintains a minimal chassis size while accommodating large components. Thanks to the relocatable PSU bracket, the A3-mATX empowers you to build a powerful and compact PC system tailored to your needs and preferences.
Features

Features:




  • Minimalistic sleek design 26.3L micro form factor chassis

  • Side and top panels are designed with steel mesh

  • Accommodates M-ATX and ITX motherboard with 4 slots 415mm large GPU

  • Supports up to 360 radiator and 10 x 120mm fans

  • Supports ATX/SFX/SFX-L and LIAN LI Edge PSU that can be mounted sideways or frontways

  • In collaboration with DAN Cases for the case design whereas manufactured and sold by LIAN LI.








OPTIONAL ACCESSORIES






VERTICAL GPU KIT (A3-1X/ A3-1W)
Supports up to 3 slots thick GPU at vertical display with an 150mm PCIe4.0 riser cable.





width=708






LEFT SIDE TEMPERED GLASS PANEL (A3-2X/A3-2W)
Display of the interior components can be achieved with the accessory.






More Details






width=750




















HARDWARE COMPATIBILITY IN ALL CONFIGURATION






Front PSU Installation
















/


A3 Front mounted PSU 2.5 slot(F2.5)? Top AIO, Installation Guide

















Side PSU Installation















/















Specifications

Specifications:


















































































MODEL NAME A3-mATX
MODEL NO. A3-mATX BLACK A3-mATX WHITE A3-mATX-WD BLACK
COLOR Black White Black (Wood Edition)
CASE TYPE MFF (Micro Form Factor)
DIMENSION (D) 443mm x (W) 194mm x (H) 321.5mm (D) 443mm x (W) 194mm x (H) 306mm(w/o feet)
CAPACITY 26.3L
MATERIAL Steel
MOTHERBOARD SUPPORT M-ATX/ITX
PSU SUPPORT ATX/SFX/SFX-L (Max 220mm)
FAN SUPPORT Top: 3 x 120mm Side: 3 x 120mm or 2 x 140mm Bottom: 3 x 120mm Rear: 1 x 120mm
RADIATOR SUPPORT Top: 1 x 360/240mm Side: 1 x 360/280/240mm Bottom: 1 x 240mm (360mm with fan at the bottom)
DRIVE SUPPORT Tray: 2 × 2.5? SSD Bottom: 1 × 2.5? SSD or 1 × 3.5? HDD
GPU LENGTH CLEARANCE Max 415mm
CPU HEIGHT CLEARANCE Max 165mm
EXPANSION SLOTS 4
I/O PORTS 1 x Power Button 2 x USB 3.0 TYPE-A 1 x USB 3.1 TYPE-C 1 x Mic 1 x HD Audio
DUST FILTER 1 x Bottom 1 x Bottom
1 x Front
WARRANTY 1 year
