Akasa Dual M.2 PCIe SSD adapter with RGB LED light and heatsink

Akasa

AK-PCCM2P-04

The Akaa Dual M.2 PCIe SSD adapter card heatsink has addressable RGB LED lights and supports M.2 drive lengths of 2230, 2242, 2260 and 2280.

Found a better price? Let us know and we'll try and match it!
Estimate shipping
4 in stock
$37.50 USD
Shipping calculated at checkout.

Pickup available at Performance-PCs.com

Usually ready in 1 hour

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

The Akaa Dual M.2 PCIe SSD adapter card heatsink has addressable RGB LED lights and supports M.2 drive lengths of 2230, 2242, 2260 and 2280.
Features


  • Illuminate M.2 SSDs with over 16.7 million colours

  • PCB exposed copper coupled with an additional heatsink design - reduces SSD heat and enhances performance

  • Superior mechanical design for easy installation

  • M.2 PCIe 3.0 x 4 NVMe to PCIe x 4 host adapter

  • Easily fits in a PCIe Gen3 x4, x8 or x16 slot

  • Supports 5V addressable LED pin
Specifications

















































Application

Converts two M.2 PCIe SSD to work in a main board PCIe x4 bus slot, reduces SSD heat, adds digital addressable RGB colour

Designed for

M.2 PCIe/NVMe (M key) SSD
2230, 2242, 2260, 2280 size M.2 SSD
5V addressable RGB LED pin headers

Material

Metal bracket, printed circuit board, exposed copper, aluminium heatsink, LEDs with diffuser

Voltage rating for LED

5V DC

Current rating for LED

0.48A

Connector

3-pin addressable RGB connector
4-pin addressable RGB connector

Certification

Gigabyte RGB Fusion, MSI Mystic Light, ASUS AURA and AsRock Polychrome

Operating Temperature

0°- 55° C

Operating system compatibility

OS independent; no additional drivers or software required

Contents

M.2 SSD to PCIe adapter card, silicon thermal pads (x2), 2.54mm 3-pin to RGB 4-pin male cable, 2-pin to RGB 4-pin female cable, mounting screws x 4, screwdriver, user manual

Product code

AK-PCCM2P-04
