Aquacomputer Aquaero 6 XT Blue USB Fan-Controller, Graphic-LCD, Touch Control, IR Remote Control

The aquaero is an absolutely autonomous working microprocessor-controlled device with USB 2.0 interface. All speed parameters and sensor values can be set and visualized in an user-friendly menu or through an even easier to use PC-software. Additionally, the graphic LC display can be used to display almost any information using the popular LCD software LCDHype.

The key features of the aquaero 6 include:

• Programmable four channel fan controller


• Graphic LC display with backlight


• USB 2.0 and aquabus interface


• Four fan outputs with up to 30 Watt of power per channel


• All fan outputs with 4-Pin plug, switchable between coltage and PWM control


• Versatile control options


• Eight temperature sensor inputs


• Flow sensor input


• Universal IR receiver


• Output for IR transmitter


• Three LED outputs


• Potential-free switch


• Two additional power outputs


• Extensive alarm options


• Acoustical alarm


• Speed signal output for status evaluation


• Expandable to a maximum of 12 fan channels

For a more thorough feature description, we recommend to download the manual: aquaero_5_6_en_2014_04_14.pdf

Several aqua computer products can be used to expand the functionality of the aquaero 6 controller. These expansions are dynamically mapped into the menus and display pages of the aquaero, creating a consitent control system rather than individual devices.

In maximum configuration, the following devices can be connected to an aquaero 6 simultaneously:

• 2x aquastream XT pumps


• 8x poweradjust 2/3


• 1x aquaero 5 LT (in this case only 4x poweradjust 2/3)


• 4x mps based devices (flow sensor, pressure/fill level sensor and D5 pump with aquabus)


• 2x farbwerk controller


• 1x Real Time Clock expansion module

Scope of delivery:

• Aquaero 6 XT controller


• Remote control aquaremote


• Four temperature sensors, length approx. 70 cm


• One internal USB cable, length approx. 100 cm


• One connection cable for speed signal or aquabus


• Manual


• Mounting material for installation into a free extension bay
