Bitspower Touchaqua XYZ Kit Set for ROG Strix Helios Chassis

BPTA-HLXYZ-KIT

Bitspower Touchaqua XYZ Kit Set for ROG Strix Helios


The Touchaqua XYZ Reservoir has a capacity of up to 180ml. The integrated design of the pump-reservoir set can be installed directly on a 240 or 360mm radiator using the sturdy aluminum bracket included. The reservoir is easy to install and requires minimal space. It can also be used as a standalone reservoir. The back is equipped with a high-performance S1 pump that is hidden from view, reduces the amount of assembly required, and is equipped with a Digital RGB LED strip. This reservoir can be installed in various modified cases.


Found a better price? Let us know and we'll try and match it!
Estimate shipping
2 in stock
$779.95 USD
Shipping calculated at checkout.

Pickup available at Performance-PCs.com

Usually ready in 1 hour

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

Bitspower Touchaqua XYZ Kit Set for ROG Strix Helios

width=1013

The Touchaqua XYZ Reservoir has a capacity of up to 180ml. The integrated design of the pump-reservoir set can be installed directly on a 240 or 360mm radiator using the sturdy aluminum bracket included. The reservoir is easy to install and requires minimal space. It can also be used as a standalone reservoir. The back is equipped with a high-performance S1 pump that is hidden from view, reduces the amount of assembly required, and is equipped with a Digital RGB LED strip. This reservoir can be installed in various modified cases.

This image is for reference purposes only - not the actual finished product.

Features

If there arenâ??t enough DRGB headers on the motherboard, you can use the Bitspower Touchaqua Digital RGB Multi Function Controller, which is available for purchase in the options below.


I wanna show off, but what's the support I'd need?


â??DRGB


The end of power supply is 3PIN. The sequence is +/D/â?? (some motherboards are shown +5V/D/â??, and the plug is like 4PIN but the 3rd PIN is empty). Please plug in the corresponding direction of motherboard, controller or the wire integrator for one to many. If choosing the motherboard as the power supply, the light effect can be synchronize with MB. Digital Controller can be purchased in options below.



Specifications

Compatibility :



  • Asus ROG Strix Helios


LED Strip Management By Bitspower Digital RGB And Certified By ASUS AURA Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, ASRock Polychrome, BIOSTAR VIVID LED DJ and Razer Chroma.


Included :


1Set of BPTA-XYZ-RES-PWM-V2
2Set of BPTAN-NLS360-F2PB
1Set of BP-WBCPUM-DRGB
1Set of BP-VG2080RD-A2
2Set of BPTA-FX1812NT-3
6Set of TA-DOTFH1420-GS
6Set of TA-90RE-GS
1Set of TA-F95-GS
1Set of TA-F60-GS
1Set of TA-F62-GS
1Set of TA-F63-GS
1Set of BPTA-TMB-GS
1Set of BPTA-RE-GS
1Set of BPTA-EFW-GS
1Set of BPTA-F06-GS
6Pcs of BP-NCCLT14AC-L500


S1 Pump Spec.
Rated voltageï¼?12V DC
Power consumptionï¼?17W
Maximum flowï¼?960L/h
Noiseï¼?40~45dBA
Maximum system temperatureï¼?60â??
PWMï¼?Yes
Electric Connectorï¼?Molex 4 Pin
Warrantyï¼?2 years


This image is for reference purposes only - not the actual finished product.


*** Bitspower reserves the right to change the product design and interpretations. These are subject to change without notice. Product colors and accessories are based on the actual product. ***

*** From 15th March 2018, all of our installation guides will be provided electronically via an easy-to-use QR code attached to the packaging. ***

*** Before filling in the water, please make sure all the components are installed correctly. To prevent any leakage which may damage the PC components, please perform a 24-hour leaking test with only the pump connected to the power supply. ***
