Model Number
|
RR-910-HTX3-G1
|
CPU Socket
|
Intel: LGA 1151, 1150, 1155, 1156, 775
AMD: FM2+, FM2, FM1, AM3+, AM3, AM2+, AM2, AM1
|
Max TDP
|
130W
|
Dimensions
|
90 x 76 x 135.9 mm (3.5 x 2 x 5.4 in)
|
Weight
|
470g (1.01lb)
|
Heatsink Dimensions
|
90 x 51 x 135.93 mm (3.5 x 2 x 5.4 in)
|
Heatsink Weight
|
379g (0.8lb)
|
Cooling Technology
|
Aluminum fin / 3 Direct Contact Heatpipes
|
Fan Dimensions
|
92 x 92 x 25 mm (3.6 x 3.6 x 1.0 in)
|
Fan Color
|
Black
|
Fan Speed
|
800 - 2800 RPM (PWM) ± 10%
|
Fan Airflow
|
15.7 ? 54.8 CFM ± 10%
|
Fan Noise Level
|
17 - 35 dBA
|
Fan Pressure
|
0.35 ? 4.27 mm H2O ± 10%
|
Fan Bearing Type
|
Long Life Sleeve
|
Fan Life Expectancy
|
40,000 hours
|
Fan Rated Voltage
|
12V DC
|
Fan Rated Amperage
|
0.26A
|
Fan Power Consumption
|
3.12W
|
Fan Power Connector
|
4-pin
|
RAM Clearance
|
36.4 mm (1.4 in)
|
Packaged Dimensions
|
245 x 150 x 105 mm (9.6 x 5.9 x 4.1 in)
|
Packaged Weight
|
500g (1.1lb)
|
Warranty
|
2 years
|
Accessories
|
All-in-one Mounting Solution, Thermal Grease, 120mm PWM Fan and 2 Fan Clip Support
|
