Coolgate Double 120mm High Density 20 FPI Heat Exchanger Radiator Coolgate Double 120mm High Density 20 FPI Heat Exchanger Radiator
Coolgate Double 120mm High Density 20 FPI Heat Exchanger Radiator
35mm

Coolgate Double 120mm High Density 20 FPI Heat Exchanger Radiator

Coolgate

CG-240HD-D

Product Details:




The Coolgate Dual 120mm Heat Exchanger is a combination of all the best rad
designs making it versatile and a performance beast. The High Density
versions have more fins per inch to increase your cooling potential!
These radiators sport a staggering 20 FPI, allowing amazing results from
a considerably thin radiator. Featuring inner tubes made of 90% copper
this series is made for high end performance.




  • HD FIN
    CONFIGURATION

    High Density FPI (fins per inch) is designed for
    highest perfomance.



  • GREEN
    ENERGY

    Protect environment by using RoHS compliant
    components, recycled materials and lead-free
    production.



  • EASE OF USE

    4 G1/4Â? threads and UNC 6-32 screw threads
    allow multiple and flexible installations and
    configurations.



  • HIGH FLOW
    OPTIMIZED

    Minimal water
    resistance and achieve optimal cooling performance.



  • THREE YEARS
    WARRANTY

    Based on long-standing professional
    research, development and production we provide full 3
    years warranty on Coolgate heat exchangers.

Specifications:


  • Material: Copper fins, brass chambers
  • Color: 2 µ black paint; copper plating optional
  • Fins spacing: 20 FPI (Fins Per Inch)
  • Dimension: 280 mm x 129 mm x 35 mm
  • Tube: Single rows, 19 mm x 2 mm
  • Connection thread: 3x G1/4Â? threads
  • Weight: 680 g
  • Liquid Volume: 105 ml
  • Pressure tested: 1.5 bar
  • Mounting: 8x N6-32 UNC on both sides for 120 mm
    fan installation



Found a better price? Let us know and we'll try and match it!
Estimate shipping
8 in stock, ready to ship
$67.95 $50.96 Sale
Shipping calculated at checkout.

Pickup available at Performance-PCs.com

Usually ready in 1 hour

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

The Coolgate Dual 120mm Heat Exchanger is a combination of all the best rad designs making it versatile and a performance beast. The High Density versions have more fins per inch to increase your cooling potential! These radiators sport a staggering 20 FPI, allowing amazing results from a considerably thin radiator. Featuring inner tubes made of 90% copper this series is made for high end performance.
Features




  • HD FIN CONFIGURATION
    High Density FPI (fins per inch) is designed for highest perfomance.






  • GREEN ENERGY
    Protect environment by using RoHS compliant components, recycled materials and lead-free production.






  • EASE OF USE
    4 G1/4Â? threads and UNC 6-32 screw threads allow multiple and flexible installations and configurations.






  • HIGH FLOW OPTIMIZED
    Minimal water resistance and achieve optimal cooling performance.






  • THREE YEARS WARRANTY
    Based on long-standing professional research, development and production we provide full 3 years warranty on Coolgate heat exchangers.
Specifications


  • Material: Copper fins, brass chambers

  • Color: 2 µ black paint; copper plating optional

  • Fins spacing: 20 FPI (Fins Per Inch)

  • Dimension: 280 mm x 129 mm x 35 mm

  • Tube: Single rows, 19 mm x 2 mm

  • Connection thread: 3x G1/4Â? threads

  • Weight: 680 g

  • Liquid Volume: 105 ml

  • Pressure tested: 1.5 bar

  • Mounting: 8x N6-32 UNC on both sides for 120 mm fan installation
