Fractal Design Celsius S24 Cooling Fan/Radiator Fractal Design Celsius S24 Cooling Fan/Radiator
Fractal Design Celsius S24 Cooling Fan/Radiator

Fractal Design Celsius+ S28 Dynamic

Fractal Design

FD-W-2-S2801

Celsius+ takes AIO water cooling to a new level with an ARGB-accented pump face, a fully redesigned block and an upgraded on-radiator PWM fan hub with ARGB support.

Found a better price? Let us know and we'll try and match it!
Estimate shipping
$169.99 Sold out
Shipping calculated at checkout.

Pickup currently unavailable at Performance-PCs.com

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

Celsius+ takes AIO water cooling to a new level with an ARGB-accented pump face, a fully redesigned block and an upgraded on-radiator PWM fan hub with ARGB support.
Features

Outstanding airflow




  • High-performance Dynamic X2 PWM fans provide excellent airflow with minimal noise




  • Optimized fan geometry balances airflow with extra emphasis on static pressure




  • Strategic blade notches diffuse noise from blade/stator interaction




  • Trip Wire technology reduces blade turbulence




  • LLS (Long Life Sleeve) fan bearings provide silent operation with a long lifespan




Get the balance right


Our intelligent auto mode dynamically adjusts the fan and pump speeds for optimized silent performance - and a simple twist of the pump face changes to PWM mode for full user control


Tidier through technology


ARGB-enabled PWM hub places all fan connections directly on the radiator for a clutter-free installation


Forget the thermal paste


With the Celsius+, the thermal paste is pre-applied to ensure a mess-free installation


Color-coordinated cooling


Your options for controlling the color effects of Celsius+ are continually growing, with current certifications including Asus AURA, Gigabyte Fusion, MSI Mystic Light, Razer Chroma and ASRock Polychrome support


Mounting made easy


Supports the most common sockets for both Intel and AMD


Up our sleeves


Braided tube sleeves readily contain both the fan control cables and ARGB wires
Specifications








General specifications






  • Sockets supported (Intel)

    1200, 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, 2066



  • Sockets supported (AMD)

    AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+, TR4 (via included bracket in AMD Threadripper box)



  • Coldplate material

    Copper



  • Thermal paste

    Pre-applied



  • Tube length

    400 mm



  • Tube material

    Low-permeability rubber with braided nylon sleeve



  • Fittings, block side

    Articulating 90-degree elbow



  • Fittings, radiator side

    Straight rotary



  • Fan control

    Dual mode (Auto/PWM)







Fan specifications






  • Fan type

    Dynamic X2 GP-14 PWM



  • Rotational speed

    500 â?? 1700 RPM



  • Bearing

    LLS



  • PWM control

    Yes



  • Acoustical noise (full speed)

    33.7 dBA



  • Maximum air flow

    105.9 CFM



  • Maximum static pressure

    1.95 mm H2O



  • Input voltage

    12V DC



  • Maximum input current

    0.25A



  • MTBF

    100,000 hours







Pump specifications






  • Rotational speed

    800-2800 RPM in normal use, 3500 RPM during thermal protection mode that activates if liquid temperature is over 60°C



  • Bearing type

    Ceramic bearing and shaft



  • PWM control

    Yes



  • Acoustical noise (full speed)

    20 dBA



  • Maximum pressure, 50°C

    1.46 mm H2O



  • Input voltage

    12V DC



  • Input current (without fans)

    0.36A



  • MTTF

    50,000 hours



  • Block height

    45 mm



  • Block measurements (with fittings)

    86 x 75 mm



  • Block diameter (main block body)

    62 mm







Radiator specifications






  • Dimensions

    143 x 30 x 324 mm



  • Housing material

    Aluminum



  • Fin material

    Aluminum



  • Fan screw threads

    6-32







Other






  • Package contents

    Celsius+ S28 unit, 2 x 140 mm fans, User manual, Mounting hardware for all listed sockets, Fan and radiator mounting screws



  • Package Dimensions

    411 x 187 x 160 mm



  • EAN

    7340172702085



  • UPC

    843276102081



  • JAN

    4537694275521



  • Product code

    FD-W-2-S2801



  • Warranty

    5 years
