Fractal Design Define 7 Solid - Black

Fractal Design

FD-C-DEF7A-01


The Define 7 is the latest pinnacle of the renowned Define series, setting a new standard for what you should expect from a mid-tower case when it comes to modularity, flexibility and ease of use.


Found a better price? Let us know and we'll try and match it!
Estimate shipping
3 in stock
$179.99
Shipping calculated at checkout.

Pickup available at Performance-PCs.com

Usually ready in 1 hour

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

Define 7

Re-defining versatility.


The Define 7 is the latest pinnacle of the renowned Define series, setting a
new standard for what you should expect from a mid-tower case when it
comes to modularity, flexibility and ease of use. The dual-layout interior,
industrial sound damping, and classic styling make it an easy choice for any
design-conscious PC builder in need of a versatile and dependable case that
accommodates ambitious builds and leaves you room to grow.
Features











Superior airflow by design


Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans.



  • Impressive cooling capacity with a total of nine 140 mm or 120 mm fan mounting positions




  • Easy-to-clean high airflow nylon filters with full PSU coverage and convenient front access




  • The single 5.25â? ODD bay can be converted to an additional 140 mm front fan mount with filtered louver covering




















6 SSD/HDD trays + 2 SSD brackets + 1 Multibracket included


Superlative storage


Convert to Storage Layout and install up to 14 HDDs alongside four dedicated SSDs mounts



  • 6 universal HDD/SSD brackets included with 14 positions total in Storage Layout




  • 2 dedicated SSD brackets included with 4 positions total




  • Versatile Multibracket converts any unused fan position to an HDD, SSD or pump mount




  • Sturdy new HDD cage design with vibration damped trays












Cable management


Integrated cable guides with Velcro ties simplifies cable management behind the board




Nexus+ 2 fan hub


Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans




Type-C interface


Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging and speeds up to 10Gbps
Specifications










Specifications






  • 3.5/2.5 Universal drive brackets

    6 included, 14 positions total



  • Dedicated 2.5 drive brackets

    2 trays included, 4 positions total



  • 5.25â? drive mounts

    1



  • Expansion slots

    7 + 2



  • Front ports

    1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button



  • Total fan mounts

    9 x 120/140 mm



  • Front fan

    3 x 120/140 mm (2 x Dynamic X2 GP-14 included)



  • Top fan

    3 x 120/140 mm



  • Rear fan

    1 x 120/140 mm (1 x Dynamic X2 GP-14 included)



  • Bottom fan

    2 x 120/140 mm



  • Dust filters

    Top, 2 x front, full length bottom



  • Fixed velcro straps

    Yes



  • Cable routing grommets

    Yes



  • Captive thumbscrews

    HDD brackets, SSD brackets, PSU bracket



  • Left side panel

    Industrial sound-damped steel



  • Right side panel

    Industrial sound-damped steel







Compatibility






  • Motherboard compatibility

    E-ATX (max 285 mm) / ATX / mATX / mITX



  • Power supply type

    ATX



  • PSU max length

    250 mm (with HDD cage installed)



  • GPU max length

    Storage layout: 315 mm - Open layout: 491 mm (467 mm w/ front fan)



  • CPU cooler max height

    185 mm



  • Front radiator

    Up to 360/280 mm



  • Top radiator

    Up to 360/420 mm



  • Rear radiator

    120 mm



  • Bottom radiator

    Up to 240/280 mm



  • Cable routing space

    30 mm



  • Vertical GPU Support (with Flex VRC-25)

    65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling







Dimensions






  • Case dimensions (LxWxH)

    547 x 240 x 475 mm



  • Case dimensions w/o feet/protrusions/screws

    533 x 240 x 451 mm



  • Package dimensions (LxWxH)

    558 x 363 x 641 mm



  • Net weight

    13.49 kg



  • Package weight

    15.98 kg



  • Volume

    57.7 liters







Other






  • Package contents

    Define 7 case. Accessory box. User manual. Ventilated top. 4 x HDD/SSD trays (for a total of 6)
