Fractal Design Prisma AL-14 RGB Cooling Fan - 3 Pack

FD-FAN-PRI-AL14-3P

Our AL Series ARGB fans allow your system to truly shine. Six hub-mounted addressable RGB LEDs work in harmony with a white semi-opaque outer ring and fan blades to produce a beautifully uniform glow across the fanâ??s entire surface.

Found a better price? Let us know and we'll try and match it!
Estimate shipping
$76.50 Sold out
Shipping calculated at checkout.

Pickup currently unavailable at Performance-PCs.com

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

Our AL Series ARGB fans allow your system to truly shine. Six hub-mounted addressable RGB LEDs work in harmony with a white semi-opaque outer ring and fan blades to produce a beautifully uniform glow across the fanâ??s entire surface.

Features

Supports Gigabyte Fusion, ASUS Aura, Razer Chroma, MSI Mystic Light and ASRock Polychrome


Prisma AL-12/14 allows precision software control, enabling Prisma to synergize perfectly with your components. If you prefer physical control, just pair Prisma with the newly released Adjust R1 controller to set colors, brightness, and motion effects with the push of a button.


As with any Fractal Design fan, silence remains a central focus with integrated vibration damping corners, silent LLS bearings, and PWM options for complete control over the speed of your fans, ensuring Prisma is seen, not heard.


Let your system shine


Support for ASUS Aura, Gigabyte Fusion, MSI Mystic Light and ASRock Polychrome allows precision software control, enabling Prisma to synergize perfectly with your components.



  • Six individually addressable hub-mounted RGB LEDs

  • Specially designed fan blades and outer ring produce an exceptionally uniform glow

  • Chainable RGB cables simplify wiring and make the most of available connections

  • Black sleeved power cables offer an extra touch of style

  • Adjust R1 RGB controller (sold separately) enables physical control of colors and effects

  • Available in 3-pack


Aerodynamic performance



  • Aerodynamic stator struts with embedded wiring reduce noise and turbulence

  • Trip Wire technology introduces a micro-turbulent layer for enhanced blade efficiency

  • Integrated vibration-damping corners made from high-quality synthetic rubber

  • LLS (Long Life Sleeve) bearings provide silent operation with a long lifespan

Specifications








Specifications






  • Size

    140 x 140 x 25 mm



  • Screw hole pattern

    125 x 125 mm



  • Connector

    3-pin



  • LED type

    Addressable RGB



  • Bearing

    LLS



  • Number of blades

    7



  • Rotational speed

    1000 RPM



  • Noise level

    19.4 dB(A)



  • Airflow (CFM)

    63.33 CFM



  • Airflow (m3/h)

    107.60 m3/h



  • Static pressure

    1.07 mmH2O



  • Fan input power

    1.2 W



  • Fan max input current

    0.30 A



  • Fan input voltage

    12 V



  • Fan starting voltage

    7 V



  • LED input power

    1.50 W



  • LED max input current

    0.30 A



  • LED input voltage

    5 V



  • MTBF

    100,000 hours



  • Fan weight

    198 g



  • Cable length

    500 mm



  • Cable type

    Black sleeved







Other






  • Package contents

    Prisma AL-14 140 mm fan, 4x fan screws / 3x Prisma AL-14 140 mm fan, 12x fan screws (3-pack)



  • Package weight

    246 g / 690 g (3-pack)



  • Package dimensions (Including hanging tab)

    202 x 142 x 30 mm / 222 x 142 x 80 mm (3-pack)



  • Package dimensions (Excluding hanging tab)

    167 x 142 x 30 mm / 177 x 142 x 80 mm (3-pack)



  • EAN

    7340172701620 / 7340172701644 (3-pack)



  • UPC

    843276101626 / 843276101640 (3-pack)



  • JAN

    4537694264174 / 4537694264204 (3-pack)



  • Product code

    FD-FAN-PRI-AL14 / FD-FAN-PRI-AL14-3P (3-pack)
