Lian Li PC-011 Mini Custom Modded Replacement Front Panel With Optional Fan and Radiator Mounting-Scaly

You landed yourself a Lian Li 011 Mini, and now you're wondering what exactly you should do with it, huh? Sure, you can follow the manual and throw together a clean looking rig, but that glass panel up front makes you wish you had some additional airflow, doesn't it?... Maybe even something kind of fun and adventurous? Well, ruminate no further because we have just the solution!

Introducing PPCS' 011 Mini Custom Panel Kits! With not one, not two, not three, but four different fan mounting plates to choose from you should be able to find a path forward that will help you manifest that dream-rig inside your head into reality. With options friendly to both air-coolers and water-coolers alike, it'll help make that mere project become an awesome project.

Made from cast acrylic, imagination, and love in the PPCS ModShop! Due to made-to-order production, they are not available for instant shipping and the Rush Fee does not apply. Panels are acrylic, so please be gentle with them as you can snap them if you're too rough with them; PPCS cannot be held responsible for broken kits after they are packed and shipped intact.

*FYI: Please understand that currently only black panel kits can be produced due to specific materials requirements. If/when it's possible to offer white, the listing will be updated; please do not inquire.*

Along with the outside front panel's aesthetics choice, you also have a choice of four different fan mounting plates (see photos for visual aid) to aid with your specific setup:

     � Dual-120mm plate aligned to the front grill vertically and horizontally to fit majority of industry-standard spacing on radiators (for awesome aligned aesthetics too!)
     � Dual-140mm plate aligned to the front grill vertically and horizontally to fit majority of industry-standard spacing on radiators (for awesome aligned aesthetics too!)
     � UniMount plate with both dual-120mm and dual-140mm fan mounting aligned to the bottom fan locations spaced to fit majority of industry-standard spacing on radiators
     � UniMount plate with both dual-120mm and dual-140mm fan mounting aligned to the top fan locations spaced to fit majority of industry-standard spacing on radiators

How to Install the Kit (see exploded image for visual aid):

� Step One:  Peel all protective paper from acrylic pieces
â?¢ Step Two:  â??Dryâ? install plate spacer, followed by fan plate to hold spacer in place
� Step Three:  Install screws through chassis holes from the outside into the fan plate, carefully hand-tightening in a criss-cross pattern starting with the corners first until all screws are mostly installed making sure the plate is aligned and plate spacer is flush against case.  Do NOT over-tighten, as PPCS cannot be held responsible for damage from mishandling of pieces and improper install.
� Step Four:  Install magnetic front panel onto front of case, and enjoy!
â?¢ Optional Step: â??Dryâ? install DEMCI filter behind magnetic front panel, which will hold it properly in place. Alternatively, you can install the ferrous frame from the DEMCI permanently to the fan mounting plate, allowing magnetized attachment.
