LIAN LI UNI Fan AL120 V2 RGB Black Single Fan Pack without controller

The Lian Li AL120 V2 Uni Fan ARGB PWM 120mm Black is a modular fan that can be used by itself or connected with up to 6 other fans. It features a daisy chain interlocking mechanism, pin-to-pin contact point for receiving power and signal, fluid dynamic fan bearing, and a controllable fan speed range on 250-2000 RPM via the L-connect software.

• Improved daisy chain design to connect 2 clusters of fans.
• AL120 V2 fan frame thickness is 28mm to provide 20% improved airflow compared to V1.
• Removable interlocking keys to provide better radiator clearance.
• Start/stop fan RPM support for a quieter environment.
• New corner lighting visible from all sides
• Only one cable is required for each fan cluster when using the provided new UNI HUB to control lighting effects via L-Connect 3.

Specifications

---

Product Name	UNI FAN AL120 V2
Model	AL120V2-1B
Colour	Black
Number of fans	1
Controller	No
Connector type	1 x 4-pin PWM + 3-pin ARGB 1 x ARGB MB Adapter
Fan dimension (W x H x D)	120 x 120 x 28mm
Material	PBT/PC/Aluminium
Rated voltage	DC 12V (Fan) & 5V (LED)
Fan speed	0, 250-2000 RM
Max. Air Pressure	2.97 mmH2O (Maximum)
Max. Airflow	77.3 CFM (Maximum)
Acoustic noise	28.7dB(A) Max
Bearing type	Fluid Dynamic Bearing (FDB)
Operate voltage	DC12V & 5V
Input power	7.2W
