SilverStone ES02-USB Remote Switch Kit

ES02 is a convenient remote switch kit designed by SilverStone to wirelessly turn on / off and reset a computer. By utilizing existing standard 2.4GHz RF wireless technology, USB 2.0 internal 9 pin connector, and power / reset pin headers on a motherboard, the ES02 kit is easy to install and use within 20 meters of a connected computer. An included Y cable ensures your computer case?s own power and reset buttons can be used concurrently with the ES02 if needed. Users looking for a simpler security solution than software access control will find ES02 to be a good alternative. Those with computers located in hard to reach area or has special usage scenarios will also find the ES02 to be very handy.

ï¿­ Control your computer from anywhere in the room using 2.4GHz RF remote

ï¿­ 2.4GHz receiver utilizing universal USB 9 pin male connector

ï¿­ Works as far away as twenty meter

ï¿­ Includes power / reset switch Y cable

ï¿­ Includes left and right angled USB adapters

Model No.	SST-ES02-USB
Adapter card
Adapter form factor	USB 2.0 9 pin male connector x 1
Operation frequency	2.4GHz
EIRP	3.76dBm (Measured max.)
Operating range	20 meter (Free space)
Environment	Operating temperature : 0â??~40â?? (32â??~104â??) Storage temperature : -40â??~70â?? (-40â??~158â??) Operating humidity : 10%~90% non-condensing Storage humidity : 5%~90% non-condensing
Net Weight	30g
Dimension	30mm (W) x 10mm (H) x 60mm (D)
Remote control
Operation frequency	2.4GHz
EIRP	3.76dBm (Measured max)
Operating range	20 meter (Free space)
Battery type	CR2032 (Lithium manganese button battery)
Nominal voltage	DC 3.0V
Battery environment	Operating temperature : -20â??~70â?? (-4â??~158â??) Storage temperature : 10â??~40â??(50â??~104â??)
