SILVERSTONE FW Series SST-FW123-RGB 120mm RGB LED Case Fan

The FW123-RGB is a SilverStone designed 120mm RGB fan for the DIY enthusiasts. It has RGB LED strip integrated within the frame and powered via PWM 4pin connector, the FW123-RGB?s speed can be adjusted by supported motherboard or fan controllers to be used for silent running builds or for cooling a high performance machine. Enthusiasts looking to upgrade RGB effects and aesthetics of their PCs will find the FW123-RGB to be an excellent choice.

ï¿­ PWM design allows 500 ~ 1800 rpm fan speed control by motherboard

ï¿­ Displays any color by use of an RGB LED control box or capable motherboard

ï¿­ Coating with special light diffusion material improves light uniformity

ï¿­ Double ball bearings for longer life and durability

ï¿­ Class-leading 18 LEDs for increased brightness

Model No.	SST-FW123-RGB
Color	Transparent fan blades, black frame
Bearing	Dual Ball Bearing
Connectors	4pin PWM for fan + 4pin RGB
Rated Voltage	12V DC
Start Voltage	9.6V
Rated Current	0.11A
Rated Power	2.04W
Speed	500 ~ 1800 rpm
Airflow	10.95 ~ 42.41 CFM
Static Pressure	0.2 ~ 2.42 mmH2O
Noise Level	19.25 ~ 23.54 dBA
Life Time	70,000 hours
Dimension	120mm (L) x 120mm (W) x 25mm (H) 4.72 (L) x 4.72 (W) x 0.98 (H)
RGB LEDs	18 PCS



Remark

* Please check to make sure the control box and motherboard RGB port that you want to connect are the same as FW123-RGB?s RGB port definition. Incorrect connection may cause malfunction or damage
