Motherboard
|
- Mini-ITX (170mm Ã? 170 mm)
|
CPU Liquid Coolers
|
- 92mm Asetek 645LT
- Requires 92mm AIO adapter plate
- 120mm AIO liquid coolers
- Requires 120mm AIO kit
- 120mmr adiator thickness + 120mm fan thickness must be < 72mm
- CPU pump block / coolant hoses must be < 55mm tall from CPU
- Limits GPU length to 187mm long
|
CPU Air Coolers
|
- Maximum of 55mm tall CPU coolers
- Coolers that require a Vented Side Panel on the CPU side
- ID-COOLING IS-60 (55mm)
- AMD Wraith Stealth (54mm)
- Cooltek LP53 (53mm)
- Coolers compatible with all side panel types (Unvented, Window, or Vented)
- Alpenföhn® Black Ridge (47mm)
- Noctua L9i/L9a
- Intel Boxed Cooler
- Cryorig C7 CU
- Cryorig C7
- Cooltek ITX30
- Phanteks PH-TC90LS
- RAIJINTEK Zelos
- Silverstone AR05
- Silverstone AR11
- SEMI-PASSIVE MODE: note these heatsinks require Unvented or Window panels, and two high static pressure 120mm fans
- be quiet! SHADOW ROCK LP (FAN REMOVED)
- Phanteks PH-TC12LS (FAN REMOVED)
- Noctua NH-L9x65 (FAN REMOVED)
- REEVEN BRONTES RC-1001b (FAN REMOVED)
- Scythe SCSK-1100 Shuriken Rev. B (FAN REMOVED)
- SCYTHE Big Shuriken 3 CPU Cooler SCBSK-3000 (FAN REMOVED)
- Thermalright AXP-100H Muscle (FAN REMOVED)
- Thermalright AXP-100 Copper(FAN REMOVED)
- Cooltek CR-701 (FAN REMOVED)
|
Fan Mounting
|
- 2x 120mm Fans
- Fans can be a maximum of 25mm thick, high static pressure fans recommended
- Recommended airflow is bottom intake, top exhaust
|
GPU / PCIe Cards
|
- Supports three(3) slot wide cards with room between side panel and card for airflow
- Card is mounted behind motherboard on a PCIe 3.0 16x Flexible Ribbon Riser
- with 120mm AIO kit
- Maximum card length: 187mm
- with Standard Inlet
- Maximum card height: 133mm
- Maximum card length: 305mm (325mm with front panel SSD tray removed)
- Maximum card width: 67mm
- with Pigtail Inlet (recommended for MSI and ZOTAC cards)
- Maximum card height: 157mm
- Maximum card length: 305mm (325mm with front panel SSD tray removed)
- Maximum card width: 67mm
- 157mm of height for GPU power connectors regardless of power cord option.
- Bifurcation riser limits the outer PCIe 16x 2.0 slot to 2 slots wide, and inner slot to a single slot card.
- Bifurcation outer slot maximum card width: 47mm
|
GPU Heatsinks
|
- Accelero Xtreme III
- MORPHEUS II (requires unvented or window side panels, high static pressure fans in bottom)
|
Storage
|
- (2x) 2.5 SSD/HDD mounting points behind front panel
- Optional (4x) 2.5 SSD/HDD mount bracket [replaces 1x 120mm bottom fan]
- Maximum two brackets for total of 8x 2.5 SSD/HDDs
- Optional (1x) 3.5 HDD mount bracket [replaces 1x 120mm bottom fan]
- Maximum two brackets for (2x) 3.5 HDD in bottom of case
|
Power Supply
|
- SFX
- Corsair SF series (up to 750W)
- SilverStone SST-SX series (up to 650W)
- EVGA SuperNOVA GM series (up to 650W)
- FSP Dagger series (up to 600W)
- SFX-L is supported, however it is a very tight fit and not recommended.
- Sliger recommends a fan guard grill or custom cables if you do go with SFX-L.
- It is recommended to mount your PSU with the fan intake facing the GPU for best thermals.
|
Front Panel I/O
|
- One USB 3.1 Gen 2 Type C to USB E header (SS+ 10 Gbit/s)
- One USB 3.0 Type A to 20-Pin Motherboard Header
- Two Audio Jacks to standard 9-Pin HD AUDIO header
|
Material
|
- Chassis
- ASTM-A-653 G30 Zero Spangle 20 Gauge Galvanized Steel
- Side Panels
- ASTM B209-10 5052-H32 0.080 Aluminum Sheet
- Feet
- Cavity Molded 75 Durometer Nonmarking Black SBR
|
Finish
|
- Powder coated chassis and panels
|
Case Dimensions (LxWxH)
|
- 13.19 x 6.26 x 8.18 - LxWxH
- 335mm x 159mm x 208mm - LxWxH
|
Volume
|
|
Weights
|
- Base Chassis (includes power cord and riser)
- 4.85lbs
- Window Panels
- 0.75lbs each
- Vented Panels
- 0.50lbs each
- Unvented Panels
- 0.80lbs each
- Packaging Material
- 1.30lbs each
|
Security
|
- 1x Kensington Lock Cutout
|
Warranty
|
|
