Thermaltake CLP0596 Frio Advanced 130mm CPU Cooler
CLP0596-D
Thank you for your submission!
We will get back to you soon.
Estimate shipping
Shipping calculated at checkout.
Pickup currently unavailable at Performance-PCs.com
Details
Thermaltake CLP0596 Frio Advanced 130mm CPU Cooler
- Heat-pipe Direct Touch Technology, Supports 230W Cooling Performance
- Dual 13cm Over-clocking Fan, PWM controllable with 800~2,000 RPM Speed
- Universal Socket Compatibility & Accessory Package
Features
Specifications
Dimension Intel Motherboard Installation Step One: Insert the four long screws through the back-plate into the four holes on the motherboard and secure them with the four plastic spacers. Step Two: Put the two Intel mounting bars along the four long screws and secure them with four nuts. Step Three: Remove two fans from the cooler before installation. Step Four: Securing the two T-mounting bars to the base of cooler by short screws. Step Five: Applying a thin layer of thermal grease Step Six: Place the assembled heat-sink onto the CPU and tighten each fixing bolts evenly. Step Seven: Place a fan to the fan duct at a slanted angle and push the top of fan until hearing a Â?clickÂ? sound. Repeat steps for the other fan. Step Eight: Connect the 4-pin wire to the motherboardÂ?s CPU fan connector. Installation is done. AMD Motherboard Installation Step One: Insert the four long screws through the back-plate into the four holes on the motherboard and secure them with the four plastic spacers. Step Two: Put the two AMD mounting bars along the four long screws and secure them with the four nuts. Step Three: Remove two fans from the cooler before installation. Step Four: Securing the two T-mounting bars to the base of cooler by short screws. Step Five: Applying a thin layer of thermal grease Step Six: Place the assembled heat-sink onto the CPU and tighten each fixing bolts evenly. Step Seven: Place a fan to the fan duct at a slanted angle and push the top of fan until hearing a Â?clickÂ? sound. Repeat steps for the other fan. Step Eight: Connect the 4-pin wire to the motherboardÂ?s CPU fan connector. Installation is done. Specifications: * Specifications are subject to change without notice.
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
P/N
CLP0596
Dimension
130.6(L) X 122(W) x 159.2(H) mm
Material
Aluminum Fins
Aluminum Base
Heatpipe
6mm x 5PCS
Weight
954g
Rated Voltage
12V
Start Voltage
6V
Rated Current
0.5A
Power Consumption
6W (Max)
Fan Speed
800~2000RPM
Max. Air Flow
88.77CFM
Max. Air Pressure
2.7 mmH2O
Noise
21~44 dBA
Connector
4
Life Expectancy
50,000 Hours
Compatibility
Intel
LGA 2011
LGA 1366
Core i7
LGA 1155/1156
Core i7 / Core i5 / Corei3
LGA 775
Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium D / Pentium 4/Pentium / Celeron D / Celeron
AMD
FM1
A-series
AM3+ / AM3
Phenom II / Athlon II / Athlon / Sempron series
AM2+ / AM2
Phenom II / Phenom / Athlon / Sempron series
* The product picture(s) is only for your reference, it may differ from the actual product.
