P/N
|
SP-650PCBxx
|
Short P/N
|
SP-650P
|
Model
|
SP-650AH2NCB-A
|
Type
|
ATX 12V v2.4 and EPS v2.92
|
Max. Output Capacity
|
650W
|
Peak Output Capacity
|
780W
|
Color
|
Black
|
Dimension ï¼?W / H / Dï¼?
|
150mm(W)x 86mm(H) x 140mm(D)
|
PFC ï¼?Power Factor Correctionï¼?
|
Active PFC
|
Power Good Signal
|
100-500 msec
|
Hold Up Time
|
> 16msec at 80% of full load
|
Input current
|
10A
|
Input Frequency Range
|
47Hz -63Hz
|
Input Voltage
|
100V-240V~
|
Operating Temperature
|
0°C to +40°C
|
Operating Humidity
|
20% to 90%,non-condensing
|
Storage Temperature
|
-20 °C to +70 °C
|
Storage Humidity
|
5% to 95%, non-condensing
|
Cooling System
|
120mm Fan: 1800 R.P.M. ± 10%
|
Efficiency
|
Meet 80 PLUS®Bronze at 115Vac input.
|
MTBF
|
100,000 hrs minimum
|
Safety Approval
|
UL/CUL/TUV/CE/FCC and BSMI
|
PCI-E Connector
|
PCI-E 6+2pin X 2
|
* Specifications are subject to change without notice.
* The product picture(s) is only for your reference, it may differ from the actual product.
