More Information
P/N |
PS-TPD-1000FNFAGU-1 |
|---|
WATTS |
1000W |
|---|
FORM FACTOR |
ATX |
|---|
MODEL |
TTP-1000AH3FCG |
|---|
MAX. OUTPUT CAPACITY |
1000W |
|---|
PEAK OUTPUT CAPACITY |
1200W |
|---|
COLOR |
Black |
|---|
DIMENSION ( W / H / D ) |
150mm(W) x 86mm(H) x 160mm(D) |
|---|
WEIGHT |
1.8kg |
|---|
PFC (POWER FACTOR CORRECTION) |
Active PFC |
|---|
POWER GOOD SIGNAL |
100-500 msec |
|---|
HOLD UP TIME |
> 16msec at 100% of full load |
|---|
INPUT CURRENT |
15A max |
|---|
INPUT FREQUENCY RANGE |
50Hz /60Hz |
|---|
INPUT VOLTAGE |
100V â?? 240V~ |
|---|
OPERATING TEMPERATURE |
0°C to + 50°C |
|---|
OPERATING HUMIDITY |
20% to 90%,non-condensing |
|---|
STORAGE TEMPERATURE |
-20°C to + 70°C |
|---|
STORAGE HUMIDITY |
5% to 95%, non-condensing |
|---|
COOLING SYSTEM |
14cm hydraulic bearing fan |
|---|
EFFICIENCY |
Meet 80 PLUS®Gold at 115Vac input. |
|---|
MTBF |
100,000 hrs minimum |
|---|
SAFETY APPROVAL |
CE/cTUVus/TÃ?V/FCC/BSMI/EAC |
|---|
PCI-E 6+2PIN |
6 |
|---|
