More Information
P/N |
PS-TPI-1250DPCTUS-T |
|---|
WATTS |
350W |
|---|
RGB FAN |
Yes |
|---|
FORM FACTOR |
ATX |
|---|
MODEL |
TPG-1250DH3FCT |
|---|
TYPE |
Intel ATX 12V 2.31 & SSI EPS 12V 2.92 |
|---|
MAX. OUTPUT CAPACITY |
1250W |
|---|
PEAK OUTPUT CAPACITY |
1500W |
|---|
COLOR |
Black |
|---|
DIMENSION ( W / H / D ) |
150mm(W) x 86mm(H) x 200mm(D) |
|---|
PFC (POWER FACTOR CORRECTION) |
Active PFC |
|---|
POWER GOOD SIGNAL |
100-500 msec |
|---|
HOLD UP TIME |
> 16msec at 100% of full load (115Vac/ 230Vac input) |
|---|
INPUT CURRENT |
15A |
|---|
INPUT FREQUENCY RANGE |
47Hz - 63Hz |
|---|
INPUT VOLTAGE |
100V - 240V |
|---|
OPERATING TEMPERATURE |
0 â?? to +50â?? |
|---|
OPERATING HUMIDITY |
20% to 90%,non-condensing |
|---|
STORAGE TEMPERATURE |
-20 â?? to +70 â?? |
|---|
STORAGE HUMIDITY |
5% to 95%, non-condensing |
|---|
COOLING SYSTEM |
14cm Riing PLUS Fan |
|---|
EFFICIENCY |
MEET 80 Plus Titanium at 115Vac input. |
|---|
MTBF |
120,000 hrs minimum |
|---|
SAFETY APPROVAL |
CE/FCC/UL/ TUV/EAC |
|---|
PROTECTION |
OPP, OVP, UVP, OCP, OTP, SCP |
|---|
