ToughArmor 2.5” U.2 NVMe SSD Mobile Rack for External 3.5” Drive Bay(168.7mm Depth)

MB601VK-1B

The ToughArmor MB601VK-1B is our next-generation rugged 2.5� U.2 hot-plug mobile rack, supporting ultra-high-speed 32Gbps data transfer with all U.2 NVMe SSDs, including those from Seagate, Samsung, Intel, HGST, Micron, and all other brands.

Found a better price? Let us know and we'll try and match it!
Estimate shipping
$99.99 USD $50.00 USD Sale Sold out
Shipping calculated at checkout.

Pickup currently unavailable at Performance-PCs.com

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

The ToughArmor MB601VK-1B is our next-generation rugged 2.5� U.2 hot-plug mobile rack, supporting ultra-high-speed 32Gbps data transfer with all U.2 NVMe SSDs, including those from Seagate, Samsung, Intel, HGST, Micron, and all other brands.

width=615

Features



























































Key Features


� Fits 1x 2.5� U.2 NVMe SSD or 2.5 SAS / SATA SSD






(NVMe U.2 host is required to accept NVMe SSD, SAS or SATA SSD)

� Installs into any standard external 3.5� device bay or floppy bay
â?¢ Uses an U.2 port (SFF-8639) to connect, requires NVMe host
â?¢ Supports the full NVMe bandwidth specification of 32 Gbps
â?¢ Ruggedized full-metal enclosure meeting flammability requirements
â?¢ 2-segment key lock for additional physical security
â?¢ Eagle-hook tray latch securely holds the tray inside the enclosure
â?¢ EMI Grounding â?? protects SSDs from electrical damage
â?¢ Anti-Vibration Technology (AVT) reduces noise and protects against environmental damage
â?¢ Active Power Technology (APT) saves power by shutting the device down when no drive is installed.
â?¢ Industry leading 3-year warranty against all defects
â?¢ Complimentary support from professionally trained US-based technical support agents

Specifications


















































































Model Number :


MB601VK-1B











Color :


Black











Support Drive Size :


1 x 2.5 U.2 NVMe SSD (Up to 15mm height)











Compatible Drive Type :


U.2 NVMe











Number of Drives :


1











Drive Bay :


1 x external 3.5 drive bay











Host Interface :


1 x U.2 connector (SFF-8639)











Power Input :


Via U.2 (SFF-8639)











Transfer Rate :


Up to 32Gbps











Support HDD Capacity :


No Limitation











Drive Cooling :


Metal heat dispersion with passive cooling











Structure / Material :


Full Metal











Support Hot-Swap :


Yes











Drive Security :


2 segment key lock











Product Dimension (L x W x H) :


168.7 x 101.6 x 25.4mm











Product Net Weight :


441g











Package Gross Weight :


506g











Drive Activity LED Indication :


Drive power: solid green; HDD access: flashing green











Package contents :


1 - Device, 1 - user manual, 10 - screw, 2 - key











U.2 Connector Insertion Rate :


10,000











Humidity :


5%~65% RH











Operating Temperature :


0°C to 60°C (32°F to 140°F)











Storage Temperature :


-35°C to 70°C (-31°F to 158°F)
