Key features of the HK V Pro series:
- Modular performance base plate
- Dual layer airflow
- Symmetrical cooling design
- Design-integrated mounting threads in the connection module
- Connection module screwed to copper base plate
- Screwless design thanks to magnetic mounting system
- aRGB board with improved connector System
Modular Pro-Performance base plate with 60 x 0.25mm fins
With 60 x 0.25mm fins, we are setting the standard for water-cooled graphics card coolers with our current PRO-Performance base plate. The PRO version is based on a generously designed cooling surface that ensures high flow rates and performance thanks to its channel geometry. The base plate of our Pro version is currently regarded as the standard in the water cooling sector.
All spacing to heat-sensitive components has been reduced to a minimum so that the heat from thermal problem zones such as the ram and voltage converters is ideally dissipated. Precision-fit spacers ensure perfect stability and the best possible distribution of forces between the cooler, the graphics card and the back plate.
The entire unit was specially designed for the ASUS RTX 5090 TUF to achieve outstanding Performance.
Dual-layer inflow and symmetrical cooling design
The dual-layer inflow and the symmetrical cooling design can be found in the current version of our HEATKILLER V GPU cooler. The increased inflow is particularly important for the ultra-performance base plate. The division of the water into two levels ensures a better flow through the cooler. The symmetrical flow paths, which have been implemented through extensive flow simulations, optimise the flow and therefore the overall performance of the HEATKILLER V cooler.
High-performance thermal pads for GDDR7 RAM
Our development department has invested a lot of time in finding the ideal thermal pads for the graphics card memory. We have found a thermal pad that lowers the temperatures around the memory compared to the very good standard pads.
Screwless front design – Easy maintenance
The newly developed magnetic mounting system enables a screwless front design. At the same time, it provides quick access for maintenance purposes or the installation of an aRGB board.
Design-integrated side connection module
To ensure optimum flow and compact dimensions, the connection module was integrated in the design. For additional stability, the connection module is screwed to the copper base plate of the cooler. Together with the screwless panelling and the backplate included in the package, the result is a cooler that looks like a single unit.
In order to achieve the best possible design, the cooler has been designed so that the electronic components of the circuit board are not visible.
Backplate and aRGB in the package
The mounting of the cooler has been completely revised. In contrast to the previous versions, the entire cooling unit is screwed to the backplate. This not only makes installation easier, but also distributes the contact pressure optimally, which further increases the cooling performance. In addition to the impressive appearance, better temperatures are achieved.
The aRGB board used now utilises a modular design and a compact plug-in system. The implementation as a circuit board ensures better durability. Thanks to the high compatibility of our LEDs, the Heatkiller V cooler can be integrated into any lighting concept. However, the plug-in system also allows the cooler to be used quite simply without any lighting.
Made in Germany
Production is performed with the utmost care on our state-of-the-art CNC machinery in Waren an der Müritz. Numerous work steps are carried out by hand and each product is perfected according to the four-eyes principle. Made in Germany as you would imagine.
